Implant parts

A range of reliable and innovative implant parts

Hader Solutions offers a broad line of prosthetic components. They are manufactured following the strictest quality control protocols that have made Swiss-made products world-famous. In this way, we ensure high quality products that dentists can rely on.

Building on our advanced Swiss technology and years of experience and research, we have designed components to ensure long-lasting, safe rehabilitations. This enables dentists to achieve excellent results in a wider range of prosthetic cases.

Our broad line of implant parts has been carefully designed to solve implant-based rehabilitations from beginning to end, in the most popular brands and platform sizes. Practitioners can choose the best option to fit even the most complicated cases.

CX BALL ABUTMENTS

Our exclusive Hader CX design (with a 2.25mm spherical attachment) allows a female insert to engage all around the ball for an increased area of retention. Further, the CX abutment offers the patient the security of an audible click. When servicing is required, three different levels of female retention are available.

Another unique feature of the CX System is the availability of a female paralleling mandrel. If the attachments are not parallel, the correction may be made by paralleling the female without sacrificing any retention or stability.

Made in Titanium grade 5 and available for several implant platforms. Available systems include: BioHorizons®, Biomet 3i®, Dentsply/Astra®, MegaGen®, Neoss®, Nobel Biocare®, Straumann®, and Zimmer®.

Temporary Abutments

Hader Temporary Abutments or Verification Cylinders are available for single tooth restorations (engaging) and multiple teeth restorations (not engaging). They are suitable for most brands and platforms systems, such as: Astratech®, BioHorizons®, Biomet 3i®, Neoss®, Nobel Biocare®, Straumann®, and Zimmer®.

They are made of high-quality Titanium Grade 5 and can be customized to every patient’s anatomical profile and needs for maximum prosthetic flexibility.

Our temporary abutment’s knurled surface allows the mechanical retention of resin restorative material, and their 10.5mm height and 3 cutting options give dentists the versatility to fit all situations.

Overall Height: 10.5 mm

Cut down option to 8mm

Cut down option to 5.5mm

Titanium Bases

All Hader Titanium Bases are made of Titanium grade 5 with a final anodization surface treatment. They are available for most implant connections in different diameters (for both engaging and not engaging systems) providing solutions for cases of single or multiple teeth restorations.

Available systems include:
BioHorizons®, Biomet 3i®, Astratech®, MegaGen®, Neoss®, Nobel Biocare®, Straumann®, and Zimmer®.







Angled Titanium Base

Our Angled abutments are compatible with angled screw channel systems and can solve problems of incorrect positioning of implants and improve the prosthesis' aesthetics and function, with a correction of screw entry from 0° to 30°.

They are available in standard height and full height (9.0 mm) with 2 optional cut heights, designed to fit all cases.

Full height: 9.0mm = 0° – 10°

Optional cut height: 7.0mm = 0° – 25°

Optional cut height: 5.0mm = 0° – 30°

Made of Titanium grade 5, our angled abutments are available for single and multiple tooth restoration, and suitable for most brands and platforms systems, such as: Astratech®, BioHorizons®, Biomet 3i®, Neoss®, Nobel Biocare®, Straumann®, and Zimmer®.

Healing abutments

For cases that cannot immediately be rehabilitated. Our healing abutments help promote soft and hard tissue healing around the implant and protect it from any debris or plaque accumulation.

We provide Healing Abutments to suit most implant systems platforms in a wide variety of diameters and collar heights. All made of high-quality Titanium grade 5 following the strictest protocols that have made Swiss products world-famous.









O’Ring Abutments

Hader O’Ring Abutments to be use with Hader attachment system in most brands, such as:
 Astratech®, BioHorizons®, Biomet 3i®, Neoss®, Nobel Biocare®, Straumann®, and Zimmer®.











Titanium Screws

Hader Titanium Screws are available made of Titanium grade 5, in a wide variety of diameters and lengths, to suit all Hader Implant Parts for most brands and platforms systems, such as: Astratech®, BioHorizons®, Biomet 3i®, Neoss®, Nobel Biocare®, Straumann®, and Zimmer®.

We also provide drivers that work precisely with all Hader Titanium Screws.









UCLA

Hader UCLA Abutments can be used for FCG or PFM crowns and custom abutments as well. They are a versatile, prosthetically useful stock abutment.

Made of Plastic (POM) with a titanium prosthetic screw









Implant Analogs and Digital Analogs

Hader Solutions offers a broad line of Implant Analogs and Digital Analogs made of Titanium Grade 5 and finished by an anodization surface treatment.

Available for both conventional impressions and 3D printed models, our implant analogs and digital analogs are suitable for most brands and platforms systems.







Scan Bodies

Hader Scan Bodies’ efficient design allow users to register cases for single and multiple unit restorations for most brands and platforms systems, as well for both intraoral and laboratory jobs.
